10.2: Special Senses - Eyes

Learning Objectives

By the end of this section, you will be able to:

• List the supporting structures around the eye and describe the structure of the eyeball
• Describe the processes of phototransduction

Vision

Vision is the special sense of sight that is based on the transduction of light stimuli received through the eyes. The eyes are located within either orbit in the skull. The bony orbits surround the eyeballs, protecting them and anchoring the soft tissues of the eye (Figure \(\PageIndex{1}\)). The eyelids, with lashes at their leading edges, help to protect the eye from abrasions by blocking particles that may land on the surface of the eye. The inner surface of each lid is a thin membrane known as the palpebral conjunctiva. The conjunctiva extends over the white areas of the eye (the sclera), connecting the eyelids to the eyeball. Tears are produced by the lacrimal gland, located just inside the orbit, superior and lateral to the eyeball. Tears produced by this gland flow through the lacrimal duct to the medial corner of the eye, where the tears flow over the conjunctiva, washing away foreign particles.

Figure \(\PageIndex{1}\): The Eye in the Orbit The eye is located within the orbit and surrounded by soft tissues that protect and support its function. The orbit is surrounded by cranial bones of the skull.

Movement of the eye within the orbit is accomplished by the contraction of six extraocular muscles that originate from the bones of the orbit and insert into the surface of the eyeball (Figure \(\PageIndex{2}\)). Four of the muscles are arranged at the cardinal points around the eye and are named for those locations. They are the superior rectus, medial rectus, inferior rectus, and lateral rectus. When each of these muscles contract, the eye moves toward the contracting muscle. For example, when the superior rectus contracts, the eye rotates to look up. The superior oblique originates at the posterior orbit, near the origin of the four rectus muscles. However, the tendon of the oblique muscles threads through a pulley-like piece of cartilage known as the trochlea. The angle of the tendon through the trochlea means that contraction of the superior oblique rotates the eye laterally. When the inferior oblique muscle contracts, it laterally rotates the eye, in opposition to the superior oblique. Rotation of the eye by the two oblique muscles is necessary because the eye is not perfectly aligned on the sagittal plane. When the eye looks up or down, the eye must also rotate slightly to compensate for the superior rectus pulling at approximately a 20-degree angle, rather than straight up. The same is true for the inferior rectus, which is compensated by contraction of the inferior oblique. A seventh muscle in the orbit is the levator palpebrae superioris, which is responsible for elevating and retracting the upper eyelid, a movement that usually occurs in concert with elevation of the eye by the superior rectus (see Figure \(\PageIndex{1}\)).

The extraocular muscles are innervated by three cranial nerves. The lateral rectus, which causes abduction of the eye, is innervated by the abducens nerve. The superior oblique is innervated by the trochlear nerve. All of the other muscles are innervated by the oculomotor nerve, as is the levator palpebrae superioris. The motor nuclei of these cranial nerves connect to the brain stem, which coordinates eye movements.

Figure \(\PageIndex{2}\): Extraocular Muscles The extraocular muscles move the eye within the orbit.

The eye itself is a hollow sphere composed of three layers of tissue. The outermost layer is the fibrous tunic, which includes the white sclera and clear cornea. The sclera accounts for five sixths of the surface of the eye, most of which is not visible, though humans are unique compared with many other species in having so much of the “white of the eye” visible (Figure \(\PageIndex{3}\)). The transparent cornea covers the anterior tip of the eye and allows light to enter the eye. The middle layer of the eye is the vascular tunic, which is mostly composed of the choroid, ciliary body, and iris. The choroid is a layer of highly vascularized connective tissue that provides a blood supply to the eyeball. The choroid is posterior to the ciliary body, a muscular structure that is attached to the lens by suspensory ligaments, or zonule fibers. These two structures bend the lens, allowing it to focus light on the back of the eye. Overlaying the ciliary body, and visible in the anterior eye, is the iris—the colored part of the eye. The iris is a smooth muscle that opens or closes the pupil, which is the hole at the center of the eye that allows light to enter. The iris constricts the pupil in response to bright light and dilates the pupil in response to dim light. The innermost layer of the eye is the neural tunic, or retina, which contains the nervous tissue containing photoreceptors.

The eye is also divided into two cavities: the anterior cavity and the posterior cavity. The anterior cavity is the space between the cornea and lens, including the iris and ciliary body. It is filled with a watery fluid called the aqueous humor. The aqueous humor helps bring nutrients to the structures of the anterior cavity and drains wastes. The posterior cavity is the space behind the lens that extends to the posterior side of the interior eyeball, where the retina is located. The posterior cavity is filled with a more viscous fluid called the vitreous humor. The vitreous humor helps support the eyeball internally, helping it maintain its spherical shape.

The retina is composed of several layers and contains specialized cells for the initial processing of visual stimuli. The photoreceptors (rods and cones) change their membrane potential when stimulated by light energy. The change in membrane potential alters the amount of neurotransmitter that the photoreceptor cells release onto bipolar cells in the outer synaptic layer. It is the bipolar cell in the retina that connects a photoreceptor to a retinal ganglion cell (RGC) in the inner synaptic layer. The axons of RGCs, which lie at the innermost layer of the retina, collect at the optic disc and leave the eye as the optic nerve (see Figure \(\PageIndex{3}\)). Because these axons pass through the retina, there are no photoreceptors at the very back of the eye, where the optic nerve begins. This creates a “blind spot” in the retina, and a corresponding blind spot in our visual field.

Figure \(\PageIndex{3}\): Structure of the Eye The sphere of the eye can be divided into anterior and posterior chambers. The wall of the eye is composed of three layers: the fibrous tunic, vascular tunic, and neural tunic. Within the neural tunic is the retina, with three layers of cells and two synaptic layers in between. The center of the retina has a small indentation known as the fovea.

Note that the photoreceptors in the retina (rods and cones) are located behind the axons, RGCs, bipolar cells, and retinal blood vessels. A significant amount of light is absorbed by these structures before the light reaches the photoreceptor cells. However, at the exact center of the retina is a small area known as the fovea centralis. At the fovea centralis, the retina lacks the supporting cells and blood vessels, and only contains photoreceptors. Therefore, visual acuity, or the sharpness of vision, is greatest at the fovea. This is because the fovea is where the least amount of incoming light is absorbed by other retinal structures (see Figure \(\PageIndex{4}\)). As one moves in either direction from this central point of the retina, visual acuity drops significantly. In addition, each photoreceptor cell of the fovea is connected to a single RGC. Therefore, this RGC does not have to integrate inputs from multiple photoreceptors, which reduces the accuracy of visual transduction. Toward the edges of the retina, several photoreceptors converge on RGCs (through the bipolar cells) up to a ratio of 50 to 1. The difference in visual acuity between the fovea and peripheral retina is easily evidenced by looking directly at a word in the middle of this paragraph. The visual stimulus in the middle of the field of view falls on the fovea and is in the sharpest focus. Without moving your eyes off that word, notice that words at the beginning or end of the paragraph are not in focus. The images in your peripheral vision are focused by the peripheral retina, and have vague, blurry edges and words that are not as clearly identified. As a result, a large part of the neural function of the eyes is concerned with moving the eyes and head so that important visual stimuli are centered on the fovea.

Light falling on the retina causes chemical changes to pigment molecules in the photoreceptors, ultimately leading to a change in the activity of the RGCs. Photoreceptor cells have two parts, the inner segment and the outer segment (Figure \(\PageIndex{5}\)). The inner segment contains the nucleus and other common organelles of a cell, whereas the outer segment is a specialized region in which photoreception takes place. There are two types of photoreceptors—rods and cones—which differ in the shape of their outer segment. Rods are specialized for low-light levels and black and white vision. Cones are specialized for high definition color vision in high light levels.

Figure \(\PageIndex{5}\): Photoreceptor (a) All photoreceptors have inner segments containing the nucleus and other important organelles and outer segments with membrane arrays containing the photosensitive opsin molecules. Rod outer segments are long columnar shapes with stacks of membrane-bound discs that contain the rhodopsin pigment. Cone outer segments are short, tapered shapes with folds of membrane in place of the discs in the rods. (b) Tissue of the retina shows a dense layer of nuclei of the rods and cones. LM × 800. (Micrograph provided by the Regents of University of Michigan Medical School © 2012)

Figure \(\PageIndex{6}\) Fovea: At the exact center of the retina is a region called the macula lutea with a depression called the fovea. At the fovea there are no blood vessels, ganglion cells or bipolar cells to interrupt light reaching the receptor cells and only cones are present. Because more light passes to the receptor cells at the fovea, it is in this region that visual acuity is the greatest. (Image and caption credits: "Retinal Cell Layers at Fovea Illustration" by Sofia Elizondo is licensed under CC BY-NC SA 4.0, modification of original "Cenveo - Drawing Anatomy of the fovea - English labels" by Cenveo. "Fovea Histology" by Jennifer Lange is licensed under CC BY-NC-SA 4.0, slide provided by the Regents of the University of Michigan Medical School © 2022.)

Errors of Refraction

Refraction refers to the ability of the lens to bend light rays as they enter on the eye so that they focus on the fovea centralis for most optimum vision. However, often due to the shape of the eye or cornea, the lens is not able to accommodate enough to focus light on the fovea centralis, instead focusing it before or beyond the fovea centralis. This leads to two of the most common vision issues: myopia (nearsightedness) and hyperopia (farsightedness).

Individuals with hyperopia experience blurry vision when viewing objects that are near to the eye. This can occur due to the eyeball being too short or the cornea being too flat. This affects the lens ability to become thick or round, which then causes light rays to focus behind the fovea centralis instead of on the fovea centralis. This leads to the blurry vision close up. Hyperopa is also called farsightedness because individuals with hyperopia can see far but they cannot see near. Hyperopia is corrected by placing a convex lens in front of the eye to properly refract light onto the fovea.

The opposite occurs in myopia. Individuals with myopia experience blurry vision when viewing objects at a distance. This can occur due to the eyeball being too long or the cornea being too curved. This affects the lens ability to flatten, which then causes light rays to focus in front of the fovea centralis instead of on the fovea centralis. This leads to the blurry vision at a distance. Myopia is also called nearsightedness because individuals with myopia can see near but they cannot see far. Myopia is corrected by placing a concave lens in front of the eye to properly refract light onto the fovea.

Figure \(\PageIndex{7}\) below shows the differences inside the eye between myopia and hyperopia.

Figure \(\PageIndex{7}\) Errors of Refraction: In hyperopia, light is focused behind the fovea, instead of on the fovea. In myopia, light is focused in front of the fovea instead of on the fovea. (Image Credit: "Refractive Error" by Scientific Animations is licensed under CC BY-NC-SA 4.0) / Labels by Harmony Folse
